链径(D)MM | 外长(L)MM | 外宽(B)MM | 拉力负荷(KN) | 破断负荷(KN) |
8 | 46 | 28 | 11.76 | 23.52 |
9 | 52 | 31 | 14.88 | 29.76 |
11 | 63 | 38 | 22.54 | 45.08 |
13 | 75 | 45 | 31.30 | 62.72 |
15 | 87 | 52 | 41.16 | 83.32 |
17 | 98 | 59 | 53.90 | 107.80 |
19 | 110 | 66 | 66.64 | 133.28 |
22 | 127 | 76 | 90.16 | 180.32 |
25 | 144 | 86 | 115.64 | 231.28 |
28 | 161 | 97 | 145.04 | 290.08 |
31 | 179 | 107 | 178.36 | 356.72 |
34 | 196 | 118 | 214.62 | 429.24 |
37 | 213 | 128 | 253.82 | 507.80 |
40 | 230 | 139 | 298.90 | 597.80 |
46 | 264 | 159 | 395.92 | 791.84 |
53 | 305 | 184 | 505.68 | 1011.36 |
