Material: 20Mn2 |
Surface treatment: spray, primary color |
Chain diameter/Dmm | Inner length/Lmm | Outer width/Bmm | Rice weight/KG | Breaking load/KN | Specification icon |
6 | 35 | 22 | 0.64 | 44 | |
7 | 35 | 24 | 0.90 | 44 | |
9 | 53 | 33 | 1.42 | 98 | |
10 | 65 | 42 | 1.75 | 125 | |
10 | 53 | 35 | 1.80 | 125 | |
11 | 64 | 40 | 2.18 | 147 | |
12 | 64 | 42 | 2.58 | 147 | |
13 | 82 | 54.6 | 3.05 | 190 | |
13 | 80 | 48 | 3.01 | 190 | |
14 | 80 | 50 | 3.55 | 200 | |
16 | 100 | 67.2 | 4.58 | 273 | |
19 | 100 | 67 | 6.50 | 320 |
